BGW Millennium Series 2TMC-2 (Discontinued)
Product Info & Specifications

The BGW Millennium Series Model 2 is available with a factory installed, internally mounted, TMC-2 Bi-Amp crossover/processor card.

This additional feature allows the user to fine tune the crossover points, equalization, attenuation and delay line all within the amplifier. The TMC-2 card is fully accessible above the input connectors on the rear of the amplifier and is protected by a metal security cover.

Modifications:

• Level Controls and LED indicators on the front panel read LF (Low Frequency) and HF (High Frequency) replacing Channel A and Channel B respectively
• Channel B input connector and bridge mono switch have been eliminated
• Output binding posts are labeled Low Frequency and High Frequency
• Signal/Chassis ground lift switch has been added
• A low frequency line level output can be installed in place of the 1/4" input-specify option

• Saves the cost of additional external crossovers and processing
• Frees up additional rack space
• Simplifies installation
• Reduces installation time
• Increased power

Level controls on the front panel normally should be set at maximum, the balance being set by the rear panel crossover level controls. Security "plug" cover for the attenuators can be installed to ensure tamper-proof volume settings.

BGW Millennium Series 2TMC-2 Specifications
Power Output IHF 4% duty cycle burst power @ max. 1% THD @ 1kHz.(ohms)	300 Watts Per Channel
Transformer Outputs (1kHz, 0.1% THD)
70/100V	300
140/200V	600
Intermodulation Distortion	Less than 0.05% at rated output (SMPTE method, 60Hz & 7kHz, 4:1 ratio)
Frequency Response	20Hz or 40Hz (selectable) to 150kHz +0, -3dB
Transformer Outputs	40Hz - 15kHz, +0, -3dB
DC Offset Voltage	Less than 10 millivolts at ouput terminals
Hum and Noise Level	100dB below rated output into 8 ohms (20Hz to 20kHz unweighted)
Min. Input Impedance (/ch)	10k ohms balanced
Input Sensitivity	0.775 Vrms for rated 8 ohm output
Voltage Gain	31.2dB, 36.3X 34.2dB, 51.3X 36dB, 63.1X
Damping Factor	Greater than 200:1 (ref. 8 ohms)
Output Regulation	100V or 70V tap; less than 1.0dB
High Pass Filter	18dB/Oct. Butterworth, internally adjustable, 20 or 40Hz
Power	100, 115, 230 VAC, 50-60Hz 650VA/480W
Dimensions
Height	3U 5.25 inches (13.3 cm)
Width	19 inch standard rack front panel (48.3 cm)
Depth (w/autoformers)	12.8", (14.6")
Weight Net/Shipping	34/38 lbs
ProNet Price	$ 1,079.00
Applications	Installed/Paging, Commercial, Live Sound, Recording/Post Production, Broadcast, Cinema/Exhibition/Presentation

• Master Level Attenuator:
  0dB to -20dB
• High Frequency Level Attenuator:
  0dB to -20dB
• Low Frequency level Attenuator:
  0dB, -10dB
• Using a 4 ohm low frequency cabinet, the power output increases at least 1db (400 watts)
• Clipping Eliminator (limiter) In/Out Switch
• Fixed 30Hz 18dB per Octave High Pass Filter for woofer over-excursion protection. Settings of 20Hz, 25Hz, 35Hz and 40Hz can be selected internally by moving jumpers
• Switch selectable 500Hz and 800Hz 24dB per Octave Linkwitz-Riley crossover filters
• Switch selectable asymmetric (Cinema) 500 Hz and 800Hz High Pass Filter for smoother acoustic roll of below crossover frequency
• Switch selectable Screen Loss Equalization
• Switch selectable Constant Directivity Horn Equalization featuring separate hinge frequency for Large Format or Small Format CD horns, continuously variable EQ control having 0 to +9dB of boost and an EQ defeat switch
• Switch selectable 700µSec and 1.9mSec Low Freuency delay line for time arrival compensation at the crossover between the physically displaced HF horn driver and LF drivers commonly used in screen channel loudspeakers (such as JBL 4670C, 4673C, 4675C, EV TS940, TS9040DLX, Altec A6 and A10.) Delay defeat switch provided for earlier systems not requiring delay
