| BGW M2200 Specifications |
| Power |
2800Watts IHF
1900 Watts Continuous |
| Amplifier Class |
AB+B (low quiescent) |
| Usable Frequency Response |
25Hz to 180Hz |
| Maximum Output (1m) |
>130dB SPL above 40Hz |
Electronic Crossover
(Linkwitzriley filters) |
SwitchSet(TM) 24dB/octave frequencies selectable at 63, 71, 80, 89, 100, 112, 125, 140, 160, and 180Hz
|
| Summing Amp |
Electronically sums dual inputs to mono |
| High Pass Output |
Post-summing amp single ended output on barrier strip, follows crossover setting |
| Sensitivity |
Adjustable from -10dBm to +16dBm (0.24 5V to 5.0V) with hi-rel locking shaft control
|
| Input Limiting |
Active above +16dBm |
| Remote Power-On |
Contact closure or 15VDC, opto-isolated |
| Power Requirements |
50-60Hz, 100-120 VAC, 30 AMps max, 16 Amps nominal, or 220-240VAC 8 Amps, 8 Amps nominal, with universal voltage transformer
|
| Cabinet Construction |
1 inch MDF, 2 inch MDF baffle, texture coat painted finish with stackable corner protectors
|
| Grille |
14 gauge perforated steel |
| Electronics Module |
26 x 23 inches, with 72CFM fan mounted over amplifier heatsink |
| Fan Control |
Variable speed, off at idle |
| Dimensions |
|
| Inches (HxWxD) |
35.00 x 42.75 x 31.00 |
| Centimeters (HxWxD) |
88.9 x 108.6 x 78.7 |
| Net Weight |
376 lbs (171 kg) |
| ProNet Price |
(Special Order Only) $ 8,000.00 |
